Mapper

M2M2

Dimensions:77.1 x 57 x 74.9mm

mapper

Key parameters

Model M2M2
Recommended applications Commercial robot, Outdoor robot,
Environment surveying, Handheld mapping
Measuring Range 0.1m - 40m
Sampling Frequency 9.2K
Rotational Speed 8Hz-15Hz
Angular Resolution 0.391°
Motor Brushless
Dimensions 77.1 x 57 x 74.9mm
Weight 165g
System Voltage 5V
System Current 750mA - 1300mA
Power Consumption 3.75W-6.5W
Output Ethernet (802.3/802.3u ) WiFi(802.11a/b/g/n/ac )
Temperature Range -5℃-45℃
Angular Range 360°
Range Resolution 3cm
Accuracy ≤5cm
Maximum Moving Speed 2m/s
Frequency Of Data Refresh 10Hz
Maximum Area 300m x 300m
Mapping resolution 0.05m
Accuracy < 0.02m
Graph Optimizing Working Time About 1 hr
Maximum Inclination Angle ±3°
Read more about RPLIDAR Mapper >
